Equipment List :
CNC MACHINING CENTERS
1 - Makino FNC-106 Machining Center w/Fanuc 11m Control
- 41.8" (X) x 23.6" (Y) x 22.6" (Z) Travel
- 15 H.P. AC Spindle; 10 - 3,500 rpm
- 30 tool ATC storage, CAT 50
1 - Fadal Machining Center w/Fadal HS88 Control
- 20" (X) x 16" (Y) x 18" (Z) Travel
- 15 H.P. AC Spindle; 7,500 rpm
- 21 tools ATC storage, CAT 40
1 – Hitachi VM 40 Mark II Machining Center w/Seicos M3 Control and digitizing probe
- 22" (X) x 16" (Y) x 20" (Z) Travel
- 15 H.P. AC Spindle; 8,000 rpm
- 20 tools ATC storage, CAT 40
1 – Hitachi VM 40 Mark I Machining Center w/Seicos MX3 Control and digitizing probe
- 22" (X) x 16" (Y) x 24" (Z) Travel, Full A axis
- 15 H.P. AC Spindle; 6,000 rpm
- 20 tools ATC storage, CAT 40 Have digitizing probes
LATHES
1 – JET 1440 engine lathe; Accurite .0002 digital readout
14” Swing; 3-1/8" Bore; 40" turning length between centers; 7 1/2 H.P.; 1500 rpm
MILLING MACHINES
3 - Bridgeport Vertical Milling Machines w/Anilam "Mini-Wizard" .0005" Resolution Readout
WELDING EQUPMENT
1 - Miller Syncrowave 350 welder; AC/DC 350 Amp; Tig Welder
1 - Lincoln Square Wave 175 welder AC/DC 175 amp; Tig Welder
1- Lincoln wire SP-175 plus; Mig Welder
1 – Powermax 1650 Plasma cutter 1 ¾” capacity continuous
GRINDING EQUIPMENT
1 – Kent 8” X 20” Wet Grinder w/Sony .0001 Digital read out
1 – Reed automatic 6” X 18”
1- Cleveland grinder
1- Norton O.D. Grinder
1- DoAll Universal Grinder
MISCELLANEOUS EQUIPMENT
1 – DoAll 18” throat variable speed automatic feed band saw Contour Saw
1 – MSC 14” dia. Variable Speed Horizontal cut-off saw
3 - Precision Rotary Index Tables
1 - Combination Belt & Disc Sander
1 – 1 ½ H.P. Floor Type Drill Press
1 - Sandblaster
1 – Bench grinder
1- Delta 10” table saw
CAD/CAM
AutoCAD, SolidWorks,
BobCAD, SurfCAM Velocity II
DNC SYSTEM, for
information control of CNC
equipment
FORK LIFTS
1 - 5,000 lb. CAT Lift Truck
w/2 Stage Mast
CNC TURNING CENTERS
1 - Mazak 250 SMY Turning Center; w/Fusion 640 Mazatrol Control;
10 ¾”Swing; 2 ½” Bore; 18” Turning Length; 35 H.P. main spindle, 15 H.P. sub-spindle;
24 Station Turret, 7 ½ H.P. live tooling w/2” positive y and 2” negative Y travel, 4000 rpm
main, 4000 rpm sub, and 5000 rpm live tooling
1 – Storm 80 w/Fanuc 21i Control
; 7” Swing; 1-5/8” Bore; 13.5” turning Length; 15 H.P. spindle; 12 Station Turret, 6000rpm
1 – Daewoo Puma 10 turning Center w/Fanuc 6T Control
; 31” Swing; 2-1/2" Bore; 26" turning Length; 20 H.P. spindle; 12 Station Turret, 3500rpm
Design & Manufacturing Solutions, LLC
The design and manufacturing
equipment we use is held to very strict
standards of accuracy!
